Solis 8520
Solis
8520
Solid Strength, Unyielding Consistency
The Power Of Superior Technology
Discover farming efficiency reimagined with Solis 8520! Experience raw power with its Heavy Duty 4-Cylinder Turbocharged Engine. Stand out from the crowd with Advance European Aerodynamic Styling and the brilliance of Stylish Twin Projector Lamps featuring DRL. Stay in command with Factory Fitted Front Weights, and trust the reliability of Super Strong Oil Immersed Brakes for superior performance.
HEAVY DUTY 4 CYLINDER TURBOCHARGED ENGINE
EASY SUPER SYNCHRO 12F+12R GEARBOX
SYNCHROMESH SHUTTLE TRANSMISSION
ADVANCE AERODYNAMIC STYLING
Technical Specifications
| ENGINE | |
| Engine Type | 4 Cylinder Turbocharged |
| Emission | Stage 3 |
| HP Category | 83 |
| No. of Cylinders | 4 |
| Aspiration | Turbocharged |
| Cubic Capacity (cc) | 4087 |
| Rated RPM | 2000 |
| Air Cleaner | Dry Air Cleaner |
| Cold Start | Standard |
| Max Torque (Nm) | 360@1300 |
| Exhaust | Updraft / Downdraft (Optional) |
| Muffler | Under-hood |
| TRANSMISSION | |
| Drive | 4WD |
| Clutch | Double |
| Gearbox | 12F+12R |
| Front Axle | 4WD |
| Transmission | Synchromesh Shuttle Transmission |
| SPEED (FORWARD | |
| Maximum Speed (Km/Hr) | 32.48 @ 2000 ERPM |
| Minimum Speed (Km/Hr) | 1.54 @ 2000 ERPM |
| BRAKES | |
| Brakes | Oil Immersed Brake |
| Type of Actuation | Mechanical |
| Parking Brake | Mechanical, Hand Operated |
| DIFFERENTIAL LOCK | |
| Differential Lock | Standard |
| PTO | |
| PTO (RPM) | 540/540E & 540/1000 (Optional) |
| PTO (Actuation) | Independent (Mechanical) |
| STEERING | |
| Steering | Power |
| ELECTRICAL | |
| Battery | 12V, 110Ah |
| Alternator | 12V , (90 Amp) |
| Seven Pin Trailer Socket | Output 12V |
| HYDRAULICS | |
| 3 Point Linkage | CAT-II |
| Stay Bars | Adjustable |
| Hydraulic Lifting Capacity (Kg) | 2500 (3000 Optional) |
| Auxiliary Hydraulic Circuit | 2SA/2DA |
| SAFETY SWITCH | |
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
| CAPACITY (Ltrs.) (+/-5%) | |
| Fuel Tank (Ltr.) | 65 |
| TURNING RADIUS | |
| Without Brakes (m) | 4.79 |
| TYRE | |
| Front | 11.4 – 24 |
| Rear | 18.4 – 30 |
| DIMENSION & WEIGHT (+/-5%) | |
| Weight (Kg) | 3310 |
| Wheel Base (mm) | 2340 |
| Overall Length (mm) | 4270 |
| Overall Width (mm) | 1975-2375 |
| Height (mm) Up to ROPS | 2730 |
| Min. Ground Clearance (mm) | 400 |
| Front Track (mm) | 1490-1850 |
| Rear Track (mm) | 1505-1905 |
| OTHERS | |
| Fuel Indicator Gauge | Standard |
| Front Tow Hook | Standard, Inbuilt in Front Weights |
| Front Weights with Std. Ballast | Front – 30*2+25*4 Rear – 34*2 (One on each Rear Wheel) |
| Trailer Hitch | Swinging Draw Bar with Rotating Tow Hook |
| Roll Over Protection | Standard |
| OPTIONAL FEATURES | |
| Cabin | Optional |
| Front Mudguard | Optional |
| Optional Tyre Size | 1) Front Tyre: 12.4×24 | Rear Tyre: 18.4×30 (R-2) 2) Front Tyre: 320/85R24 | Rear Tyre: 460/85R30 3) Front Tyre: 12.4×24 | Rear Tyre: 13.6×38 4) Front Tyre: 9×16 | Rear Tyre: 18.4×30 5) Front Tyre: 9×16 | Rear Tyre: 13.6×38 6) Front Tyre: 13.6×24 | Rear Tyre: 16.9×34 7) Front Tyre: 12.4×24 Rear Tyre: 340 / 85 R38 |
| Front and Rear Weights | Front 25×2 Rear Weights: 2×34 Kg on Each Whee |
